Dc 4.5v 6v 8v 12v 36v 48v 60v Digital Hour Meter For Outdoor Generator

Runleader RL-HM008B Digital LCD Hour Meter features a 6-digit, 7 segment LCD display, Automatic data storage for up to 25+ years; Total hour can be reset. Applicable voltage: DC 4.5V to 60V , Easy to install , Snap-in design and fits standard panel cut-out.(Warranty:2 Years)
(Note:Inclusion bracket)

For more than 10 years, Runleader has focused on product development and manufacturing in the fields of hour meter, battery indicator, multi-function meter, days timer,service for the garden machinery industry, outdoor power vehicle equipment, transportation vehicles, such as: generators, pumps,chainsaws,outboards,lawn mowers,compressors and others,provide well-known European and American customers with quality products and services.

1.Hour Meter (TOT) FeaturesHelp you track how many hours you put on your machine.

• Flashing hourglass icon indicates when the hour meter is accumulating time.
• Display shows total run time of machine and remains visible.
• Data is automatically stored when the external power is turned off.
• Total Hours reading displays from 0 to 999,999 Hours, 0.1 hour accuracy.
• Total hours are non-resettable.

2.Hour Meter Pin Connection

• Wiring pin has polarity,  DC power supply is suitable

• Connect the pins correctly which on back of hour meter and the meter starts working.
• Direct connection to pins,wiring pin has polarity, DC power supply is suitable.
• Can connect the key-switch to turn the meter display on or off.
• The product contains instructions, which have a detailed introduction to this part.

3.Runleader has established a complete laboratory for testing and improving the product's quality

High Pressure Water Washer Testing

• Display with PC transparent board can keep it away from the damp or moist.
• It also prevent the strong shock when it is cleaning.

Drop testing

• Favorable anti-vibration performance can suffer strong vibrations when the equipments is working.

High & Low temperature

• It can works well in temperature environments temperature: -40 °C - +70 °C.

4.Installation method

(A) Applications Installation---- Snap-in design and fits standard panel cut-out

• Snap-in design and fits standard panel cut-out; Panel Cutout Size:Approx 37.5×24.5mm(1.5×1 Inch).
• The mounting bracket is included in the product
• The rubber sleeve is mounted on the mounting bracket to make the installation more tight and more resistant to vibration.

(B)Applications

• This hour meter suitable for Outdoor Power Equipment, Generators、Agriculture、Construction Machinery、Vehicles、Boats etc... such as:Lawn Mower Garden Tractor Riding mower Leaf Blower Pressure washer Snowblower Brush Mower Line Trimmer string trimmer Pressure Washer Portable inverter generator Motorcycle Dirtbike ATV UTV Scooter Paramotor Harley dual-sport bike Golf cart Outboard Jetski Pontoon boat Mercury Raceboat Hovercraft etc...

About after-sales

All hour meter products in Runleader stores come with a Two-year warranty. If you have any product problems or logistics problems, you can contact our customer service at any time.Our store customer service will definitely help you solve it .
